Edge banders
scm Casadei automatic edgebander Flexa 607
The Casadei Flexa 607 and Flexa 607XE (Electronic Version) are heavy-duty, industrial automatic edgebanding machines engineered by the SCM Group for medium-to-large woodworking shops and industrial furniture manufacturers. Designed to process coiled edge materials (PVC, ABS, melamine, veneer) as well as solid wood strips, these machines deliver high-precision edge application and fine finishing at feed speeds up to 18 m/min.
Machine Structure & Feed System
Heavy-Duty Steel Base: Torsion-free welded steel frame designed to absorb vibrations and guarantee structural stability during continuous operation.
Track Feed System: Precision transport chain with high-friction rubber pads running on hardened steel guideways to prevent panel shifting.
Top Pressure Belt / Rollers: Heavy-duty top pressure beam with double rows of rubber rollers (or motorized pressure belt) ensuring uniform panel hold-down.
Infeed & Glue Application Units
Pre-Milling Unit (RT-V): Dual counter-rotating diamond cutterheads remove edge imperfections and chip-outs from panel edges prior to gluing.
Granulate Glue Pot (GP-V): Teflon-coated quick-melt glue basin for EVA/PUR hot-melt adhesives, featuring automatic temperature lowering during idle periods to prevent glue degradation.
Pneumatic Pressure Zone: Multi-stage roller pressure section with pneumatic pressure control to guarantee seamless bond lines.
Processing & Finishing Units
End Trimming Unit (K-2): High-precision dual-motor end trimmers mounted on linear guides for straight and chamfered cutting of leading and trailing edges.
Fine Trimming Unit (R-V): Top and bottom trimming motors equipped with multi-profile radius and straight cutters.
Corner Rounding Unit (ROUND 2M / 4M): Motorized corner rounding unit for smooth, seamless processing of panel edges and corners without stopping the workpiece.
Edge Scraping & Glue Scraping Units (RAS-V / SCR): Removes cutter marks from PVC/ABS edges and cleans surplus glue from panel surfaces.
Buffing / Hot Air Units (BF-V / PH-V): Textile buffing wheels to restore edge luster and smooth out material discoloration.
Key Difference: Flexa 607 vs. Flexa 607XE
Flexa 607 (Standard): Features manual setup adjustments with digital readouts for unit positioning.
Flexa 607XE (Electronic / Full Numerical Control): Features full axis control via servo motors. Allows instant changeovers between different edge profiles (e.g., R1, R2, solid wood) directly from the control panel without manual mechanical adjustments.
Technical Data Sheet
| Specification | Flexa 607 (Standard) | Flexa 607XE (Electronic) |
|---|---|---|
| Manufacturer | SCM Group / Casadei | SCM Group / Casadei |
| Model | Flexa 607 | Flexa 607XE |
| Panel Thickness | 10 – 60 mm | 10 – 60 mm |
| Edge Material Thickness (Coil) | 0.4 – 3.0 mm | 0.4 – 3.0 mm |
| Edge Material Thickness (Strips) | up to 8 / 12 mm | up to 8 / 12 mm |
| Min. Panel Length | 140 mm | 140 mm |
| Min. Panel Width | 60 mm | 60 mm |
| Feed Speed | 12 / 18 m/min | 12 / 18 m/min |
| Pre-Milling Cutterheads | Diamond (PCD), H 65 mm | Diamond (PCD), H 65 mm |
| Glue System | EVA / PUR Hot Melt | EVA / PUR Hot Melt |
| End Trimming Motor Power | 2x 0.35 kW | 2x 0.35 kW |
| Fine Trimming Motor Power | 2x 0.55 kW | 2x 0.55 kW |
| Corner Rounding Motors | 2 or 4 Motors | 2 or 4 Motors (NC Axis) |
| Control Unit | Master 300 / PLC | Touchscreen NC Axis Control |
| Pneumatic Connection | 6 – 8 bar | 6 – 8 bar |
| Operating Voltage | 400 V / 50 Hz / 3 Ph | 400 V / 50 Hz / 3 Ph |
| Overall Length (approx.) | ~ 5,800 – 6,500 mm | ~ 5,800 – 6,500 mm |
For professional sales and expert service, Mischi in Gargazon is your authorized casadei, scm group partner. From expert advice to choosing the right machine, from maintenance to spare parts supply and technical support, Mischi is your expert contact.
scm Casadei edge bander with controlled axes Flexa 507
Panel thickness 8 (13) ÷ 60 mm
Roll material 0.4 ÷ 3 mm
Strip edge thickness 0.4 ÷ 8 mm (12 mm optional)
Feed speed 10 ÷ 18 m/min
The FLEXA 507 automatic edgebander offers optimal solutions for all edgebanding requirements. Its flexible configuration options, the option to equip the XE version with controlled axes, and its high feed speed make the Flexa 507 an extremely versatile, modern machine.
The extremely robust construction and precision components ensure maximum precision and reliability during processing.
Flexibility: Thanks to a wide range of optional accessories and equipment, the machine is extremely flexible and suitable for any processing requirement.
scm Casadei Kantenanleimmaschine Flexa 53
For professional sales and specialized assistance, Mischi in Gargazon is your authorized scm group casadei partner. From expert advice to choosing the right machine, from maintenance to spare parts supply and technical support, Mischi is your competent partner.
SCM Casadei Edgebanding machine Flexa 43
max. Kanten 6 x 60 mm
Vorschubgeschw. 12 m/min
SCM Casadei edge banding machine Flexa33
Flexa 33 RMA8
Sps Steuerung SmartControl S
mit 10" Touchbildschirm
Optional mit 15" Touchbildschirm
max. Kanten 6 x 50 mm
Plattenstärke von 8-60 mm
Vorschubgeschw. 10 m/min
Fügeaggregat
Leimstation mit mit Rolle
und Schnellwechselbecken GP/Fast-K
und Schnellentladungsfunktion für einen
schnellen Leimfarbenwechsel
Schere für Rollenware
Kappaggregat mit 2 Motore
Eben und Rundungsfräsaggregate
oben und unten mit Nestingabtaster
Eckenrundungsfräsaggregat A/1P bis
zu einer Plattenstärke von 60 mm
Katenziehklinge mit Nestingabtaster
Flächenziehklinge
Sprühvorrichtung zum Polieren der Kante
Schwabbelaggregat
scm Casadei eage banding machine with pre milling and round Flexa 23
pre milling unit unit with diamond cutter
Non-stick spray unit
Automatic strip and roll loading station
Glue application with roller
Exchangeable tanks for PU adhesive (total 2 tanks)
Crosscut and corner rounding unit
Top and bottom planing unit with nesting unit
Surface scraper
Edge scraper with nesting unit
Buffing unit
Machine length 315 cm
Sheet material from 8 to 50 mm
Roll edgebanding material from 0.4 to 3 mm
Strip material from 0.5 to 5 mm
scm Casadei edgebanding machine Flexa 17S
Dimensions: 3000 x 525 mm
Min. ÷ max. thickness of rolled edges: 0.4 ÷ 3 mm
Max. thickness of edges in strips: 5 mm
Min. ÷ max. panel height: 8 ÷ 50 mm
Min. panel length/width: 190/110 mm
Min. panel length/width with cutting/rounding unit: 120/110 mm
Feed speed: 7 m/min
Easy operation with complete features: The Flexa17S, with edge banding and trimming of solid wood strips up to 5 mm thick, offers the best performance among edgebanding machines in its class.
These features, combined with its ease of use, make it the perfect edgebanding machine for small woodworking, furniture, and panel processing businesses.
Compared to its predecessor, the Flexa17S has been improved and enhanced with a new cutting and rounding unit. This new unit enables further processing, resulting in significant time savings and ease of operation.
This technological solution is unique in its category, as such processing capabilities are typically only available on more expensive, higher-end machines.
Jointing unit with diamond cutter
Anti-stick spray unit
Automatic strip and roll loading station
Adhesive application with roller
Optional PU adhesive exchange tank
Crosscut and corner rounding unit
Top and bottom planing unit with nesting unit
Surface scraper
Edge scraper with nesting unit
Buffing unit
Machine length 315 cm
Sheet material from 8 to 50 mm
Roll edgebanding from 0.4 to 3 mm
Strip material from 0.5 to 5 mm
scm minimax Kantenanleimmaschine ME35
minimax me 35
dimensions: 3000 x 525 mm
Min. ÷ max. thickness of rolled edges: 0.4 ÷ 3 mm
Max. thickness of edges in strips: 5 mm
Min. ÷ max. panel height: 8 ÷ 50 mm
Min. panel length/width: 190/110 mm
Min. panel length/width with cutting/rounding unit: 120/110 mm
Feed speed: 7 m/min
Easy operation with complete features: The Me35, with edge banding and trimming of solid wood strips up to 5 mm thick, offers the best performance among edgebanding machines in its class.
These features, combined with its ease of use, make it the perfect edgebanding machine for small woodworking, furniture, and panel processing businesses.
Compared to its predecessor, the Me35 has been further improved and enhanced with the new cutting and rounding unit. This new unit enables additional machining operations, resulting in significant time savings and ease of use.
This technological solution is unique in its category, as such machining capabilities are typically only available on more expensive, higher-end machines.
* with premilling unit with two motors, each 1.5 kW, 12,000 rpm
* Roll material shear from 0.8-2 mm
* Glue tray with glue roller for 3 kg
* Replacement tray for 3 kg (color change) optional
* 3-roll printing unit
* Feed speed 13 m/min
* Preheating lamp
* Top and bottom rounding milling
* Front and rear corner copying
* Edge scraper
* Spraying agent before buffing
* Buffing unit
- Roll material 0.4-2 mm
- Panel thickness 15-50 mm
- Min. panel 70 x 200 mm
- PLC control touchscreen
- Roller bearings up to D 550 mm
- Operating pressure 6 bar
- CE version
- Machine dimensions 390 x 70 x 150 cm
