AES FLEXA PRO – CNC Nesting Center (3200 x 2100 mm)

New machine – Available immediately from stock!

The AES FLEXA PRO from the AES Group (Bursa) is the ideal nesting solution for precise, waste-optimized cutting and complete machining of panel materials in modern furniture and interior design.

Product Description

With a generous working area of ​​3200 x 2100 mm, the AES FLEXA PRO enables the efficient machining of large-format panels in a single operation. The powerful 9 kW electric spindle, together with the integrated unit mount, ensures maximum flexibility for milling, grooving, and sizing operations, as well as the use of special and angle units.

Thanks to the professional software package consisting of Alphacam CAD/CAM and the Alphacam Xnesting module, you benefit from fast work preparation, minimal waste, and optimized toolpaths.

Technical Data & Features Overview

*Manufacturer / Model
*AES Group (Bursa) FLEXA PRO
*Condition: New machine
*Availability: Immediately available from stock
*Machining area: 3200 x 2100 mm
*Main spindle: 9 kW electric spindle
*Aggregate interface: Integrated aggregate mount
*Tool changer: 12-position tool changer
*Vacuum supply: High-performance vacuum pump with 250 m³/h
*Table layout: Grid table divided into 4 vacuum zones
*Operation: Ergonomic hand control (handheld terminal)
*Software package: Alphacam CAD/CAM & Alphacam Xnesting module

*Safety device: Light barrier safety system (set)

Feature Highlights

*Highly efficient nesting vacuum concept: The grid table is divided into 4 flexibly switchable zones. Together with the 250 m³/h vacuum pump, this ensures extremely secure workpiece clamping force
  – both with full loading and with      smaller nested parts.
*Extended machining options: The unit mount allows the use of various angle and special units (e.g., for mortise milling or horizontal drilling).
*Waste-free production: The Alphacam Xnesting module automatically calculates the optimal nesting plans for your components, saving expensive sheet material and significantly reducing machining times.
*Convenient handling: The mobile handheld control allows for easy machine setup, quick zero-point approach, and flexible operation directly at the work area.
*High occupational safety: The included light barrier safety system reliably secures the work area without compromising ergonomics during loading and unloading.
